economical pcb handling afb(1)

Economical series

Our Economical Series are user friendly PCB handling machines with a basic design and simple & quick setup. Like all our machines, they are very durable and solid, providing you the highest level of reliability in your production. This Series provides all basic handling capabilities at a low price range, making them the ideal entry-level portfolio for your production facility. They are the ideal option for large production facilities that run large volumes with low product mix. On top of that, you will experience the quality and service that Nutek stands for.

standard pcb handling afb

Standard series

Our Standard Series has a high level of flexibility at a mid-price range. It distinguishes itself from the Economical Series by having more options for automation, so it can be easily converted to your requirements. Just like the Economical Series, Standard Series is solid and durable. Combined with the many options for customisation, this makes them the model of choice for many of our customers. Feel free to contact us to discuss your wishes and look at the most clever solution for your product together with one of our specialists.

advanced pcb handling afb

Advanced series

When you choose for the Nutek Advanced series, we guarantee that you are future-proof. These high-end machines are versatile, have high flexibility and will help reduce production costs. All of our Advanced machines are Hermes and Industry 4.0 ready. Automatic product changeovers, preparation of the line control software, a large database of product recipes, multiple machine-to-machine communication options, the Advanced series is ideal for quick and easy product changeover. Become Advanced and feel free to contact us for a change.

a nta n ser eco

N-SER

REMOTE ACCESS SERVICE

Nutek support is alwys virtually present with our N-SER. Our advanced series contains many sophisticated features to support you in your production. With the possibility to always access our support, you can make optimal use of these features. The N-SER is there to establish a safe connection to provide remote support.

  • Remote support is more flexible; support calls can be scheduled easier.
  • Remote support eliminates travel, saving on travel-related service expenses and environmental impact.
  • Remote support has the shortest response time.
  • N-SER brings support closer, instead of hours of searching through manuals you could ask support.

N-SER CONNECTION

Nutek support connects to a cloud server to activate a connection with your N-SER and opens a VPN tunnel (the VPN tunnel is a virtual network connection with each packet encrypted before it is sent). This allows Nutek Support to communicate securely with the machines connected to one of the four network ports on the N-SER. Via this remote connection, we offer remote service, enabling us to troubleshoot, control the machines, read and change the machine data and load new software on the machines. Remote service is much quicker at lower costs, allowing service also in cases where you would normally not request Nutek support on site.

  • Help with operator issues, show how to operate the machine.
  • Troubleshoot issues while the machines are in production.
  • Upgrade machine

FLEXIBILITY

To use the N-SER, the N-SER needs to be connected to the internet. The N-SER has multiple options.

  • 4G mobile phone network.
  • Wi-Fi network with internet access (guest Wi-Fi).
  • Wired network connection (to a network with internet access).
  • Tethering using a personal hotspot on a mobile phone.
a nta n ser 2

WHEN CONNECTED

The N-SER makes an IP connection to the machine(s) connected to the four LAN ports. On the service PC, a new network adapter connects the PC with the attached machines. With this connection,

Nutek is able to:

  • Use the display as on the machine.
  • Download log files.
  • Backup machine data, and recover settings and products.
  • Upgrade machine software with new features.

SAFE AND SECURE

Security was the main focus when the N-SER was developed. The N-SER data security is maintained and monitored by a specialized company.

The N-SER has a connection for a switch that enables or disables access through a VPN tunnel. Connecting a key switch allows the N-SER to be online while the VPN connection is disabled.

Three parts ensure the data in the VPN tunnel but also on the office networks is safe.

A firewall blocks traffic that is not allowed to go through. The N-SER has two firewalls. One on your side blocking all traffic not intended for our support, preventing anyone from the other side to peek at the data on your network. The one at our side is preventing any traffic from outside support to enter the remote connection. Between the firewalls all data is encrypted so no one can see, change or add any data in the connection.

This way any data or senders with malicious intent from the Nutek company network, the internet or the guest Wi-Fi or customer office network are prevented from using or entering the VPN connection.



THE N-SER,... VPN SERVICE LIKE NO OTHER!

Theoretically, a customer VPN would function the same as our VPN. But in practice, other VPNs do not provide the same answer as our N-SER. VPN service needs maintenance and regular testing to be reliable. Changes in the customer network, updates in the VPN software or connection with another PC could cause the VPN connection not to work. The N-SER always works when it’s needed.

GENERAL SPECS N-SER

  • Dimensions 111 x 95 x 28
  • Parts 5x GbE (4x LAN, 1x WAN, 1x USB2.0)
  • Power supply 12-24 VDC =/- 20% LPS 2A
  • Power consumption About 2.5 to 5 Watt (idle)
  • Temperature range -20˚C to 65˚C
  • Physical specs Metal case, IP20, DIN rail mountable
  • Warranty 2 years
  • N-SER Cloud Lifetime access included
