STANDARD FEATURES - CHAIN CONVEYOR
- Multi zone concept available, standard segment length is 1000 mm.
- No PLC control (free running)
- Low maintenance and extended lifetime due to unique sliding insert.
- Enhanced stability.
- Conveyor width adjustment using hand crank.
- CE certified.
CHAIN OPTIONS - CHAIN CONVEYOR
OPTIONS
- Non standard conveyor/segment lengths
- Variable speed
- PLC package; incl. alarm buzzer, SMEMA interface, outlet stopper and sensor
- Fixed end stopper
- Other options available on request
SPECIFICATIONS
Transfer height
950 mm ± 25 mm *
Colour
RAL 9002 *
Flow direction
Left to Right *
Fixed rail
Front *
Machine interface
not available
Conveyor speed
6 m/min *
PCB edge support
3 mm *
Component clearance
Top 30 mm, bottom 30 mm *
Power supply
230 VAC/50 Hz/1 Ph
Power consumption
100 VA max.
* or specify
Machine Sizes
M
STANDARD LENGTHS "L"
1000, 2000, 3000, 4000
Machine L x W x H (mm)
“L” x 538 x 1000
Weight (Kg)
Depends on length
PCB Length (mm)
80 - 460
PCB Width (mm)
75 - 250
MACHINE SIZES
L
STANDARD LENGTHS "L"
1000, 2000, 3000, 4000
Machine L x W x H (mm)
“L” x 695 x 1000
Weight (Kg)
Depends on length
PCB Length (mm)
80 - 460
PCB Width (mm)
75 - 407
MACHINE SIZES
XL
STANDARD LENGTHS "L"
1000, 2000, 3000, 4000
Machine L x W x H (mm)
“L” x 795 x 1000
Weight (Kg)
Depends on length
PCB Length (mm)
80 - 460*
PCB Width (mm)
75 - 460*
* or specify
